| BLC | Supported |
| Dewarping | Supported |
| Digital noise reduction | 2D/3D DNR |
| Flip | Normal/Vertical/Horizontal/180° |
| HLC | Supported |
| Smart IR | Support |
| White Balance | Auto/Outdoor/Fine Tune/Sodium Lamp/Locked/Auto2 |
| Network |
| Client | EZStation
EZView
EZLive |
| Compatible Integration | ONVIF(Profile S, Profile G, Profile T), API |
| Protocols | IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP,QoS |
| Web Browser | Plug-in required live view: IE9+, Chrome 41 and below, Firefox 52 and below
Plug-in free live view: Chorme 57.0+, Firefox 58.0+, Edge 16+, Safari 11+ |
| Video |
| Frame Rate | Main Stream:2MP (1920×1080): Max. 20 fps;
Sub Stream: 720P (1280×720): Max. 20 fps;
Third Stream: 4CIF (704×576): Max. 20 fps |
| H.264 code profile | Baseline profile, Main Profile |
| Motion Detection | Up to 4 areas |
| OSD | Up to 4 OSDs |
| Privacy Mask | Up to 4 areas |
| ROI | Up to 2 areas |
| Video Bit Rate | 128 Kbps~16 Mbps |
| Video Compression | Ultra 265, H.265, H.264, MJPEG |
| Camera Features |
| Electronic Shutter Speed | Auto/Manual, 1~1/100000 s |
| Environment | Working Environment -30°C ~ +60°C (-22°F ~ 140°F), Humidity: ≤95% RH(non-condensing)
Strorage Environment -30℃ ~ 60℃ (-22°F ~ 140°F), Humidity: ≤95% RH (non-condensing) |
| Minimum Illumination | Colour: 0.02 Lux (F2.0 AGC ON)
0 Lux with IR on |
| Viewing Angle | Angle of view(H) 86.5°
Angle of View (V) 44.1°
Angle of View (O) 106.4° |
| Storage | Edge Storage: Micro SD, up to 256 GB
Network Storage ANR |
| Lens | 4.0mm@F2.0 |
| Others | Sensor: 1/2.7", 2.0 megapixel, progressive scan, CMOS
Day/Night: IR-cut filter with auto switch (ICR)
S/N >52dB
IR Range: Up to 30m (98 ft) IR range
Wavelength: 850nm |
| General |
| Certification | CE: EN 60950-1
UL: UL60950-1
FCC: FCC Part 15 |
| Dimensions | 162.6 × 62.4 ×62.7 mm (6.4” × 2.5” × 2.5”) |
| Interface | Network : 1 RJ45 10M/100M Base-TX Ethernet |
| Power | DC 12V±25%
Power consumption: Max 5.5 W |
| Weight | 0.25 kg (0.55 lb) |
| Material | Metal + Plastic |
| Others | Wireless Standards IEEE802.11b/g/n
Frequency Range 2.4 GHz ~ 2.4835 GHz
Channel Bandwidth 20 MHz Support |
