Gigabyte GA-H110M-DS2 Micro ATX Motherboard
| Regular Price | 9,800৳ |
| Status | In Stock |
| Product Code | 3448 |
| Brand | Gigabyte |
Short Details
- Model: Gigabyte GA-H110M-DS2
- Form Factor: Micro ATX
- CPU Support: Intel 7th/6th Gen i3, i5, i7 processors
- Memory: Dual Channel DDR4, up to 32GB
- Graphics: Integrated Intel HD Graphics, 1GB shared memory, 1920x1200@60 Hz (D-Sub)
- Storage Interface: Dual Ultra-Fast SATA
Contact for bulk quantity:
0 1733-080376
,
01733-080350
,
- Model: Gigabyte GA-H110M-DS2
- Form Factor: Micro ATX
- CPU Support: Intel 7th/6th Gen i3, i5, i7 processors
- Memory: Dual Channel DDR4, up to 32GB
- Graphics: Integrated Intel HD Graphics, 1GB shared memory, 1920x1200@60 Hz (D-Sub)
- Storage Interface: Dual Ultra-Fast SATA
Specification
| Information | ||
| Supported CPU | Support for 7th/6th Generation Intel® Core™ i7 processors/Intel® Core™ i5 processors/Intel® Core™ i3 processors/Intel® Pentium® processors/Intel® Celeron® processors in the LGA1151 package * For 7th Generation Intel® Core™ processors support need to update the latest BIOS. L3 cache varies with CPU |
|
| Chipset | Intel® H110 Express Chipset | |
| BIOS | 2 x 64 Mbit flash Use of licensed AMI UEFI BIOS Support for DualBIOS™ PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 |
|
| Form Factor | Micro ATX Form Factor; 22.6cm x 17.4cm | |
| Expansion Slots | ||
| PCI | 1 x PCI Express x16 slot, running at x16 (The PCI Express x16 slot conforms to PCI Express 3.0 standard.) 2 x PCI Express x1 slots (The PCI Express x1 slots conform to PCI Express 2.0 standard.) |
|
| Memory | ||
| Type | Dual channel DDR4 memory architecture | |
| Slots | 2 x DIMM | |
| Supported Memory | Support for DDR4 2400/2133 MHz memory modules Support for ECC UDIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode) Support for non-ECC UDIMM 1Rx8/2Rx8/1Rx16 memory modules |
|
| Maximum Memory | 32 GB | |
| Graphics | ||
| Graphics | 1 x D-Sub port, supporting a maximum resolution of 1920x1200@60 Hz | |
| Max Shared Memory | 1024 MB | |
| Connector & Ports | ||
| HDMI | 1 x HDMI | |
| D-Sub (s) | 1 x D-Sub | |
| USB (s) | Chipset: 4 x USB 3.0/2.0 ports (2 ports on the back panel, 2 ports available through the internal USB header) 6 x USB 2.0/1.1 ports (2 ports on the back panel, 4 ports available through the internal USB headers) |
|
| LAN Port (s) | Realtek® GbE LAN chip (10/100/1000 Mbit) | |
| Supported Storage | 4 x SATA 6Gb/s connectors | |
| Audio | Realtek® ALC887 codec High Definition Audio 2/4/5.1/7.1-channel * To configure 7.1-channel audio, you have to use an HD front panel audio module and enable the multi-channel audio feature through the audio driver. Support for S/PDIF Out |
|
| Internal I/O Ports | 1 x 24-pin ATX main power connector 1 x 4-pin ATX 12V power connector 4 x SATA 6Gb/s connectors 1 x CPU fan header 1 x system fan header 1 x front panel header 1 x front panel audio header 1 x S/PDIF Out header 1 x USB 3.0/2.0 header 2 x USB 2.0/1.1 headers 1 x Clear CMOS jumper |
|
| TPM (Trusted Platform Module ) | 1 x Trusted Platform Module (TPM) header | |
| Warranty Information | ||
| Manufacturing Warranty | 03 Years | |
Description
Gigabyte GA-H110M-DS2 Micro ATX Motherboard Best Price in Bangladesh 2024
For PC enthusiasts and professionals in Dhaka, Bangladesh, finding the right motherboard that balances performance, compatibility, and value is essential. The Gigabyte GA-H110M-DS2 Micro ATX Motherboard stands out as a top choice, offering a robust set of features designed to meet the needs of both casual users and demanding professionals. Whether you're building a new system or upgrading your current one, this motherboard provides the perfect foundation for your PC.
Designed for High Performance and Versatility
The Gigabyte GA-H110M-DS2 Micro ATX Motherboard is engineered to deliver exceptional performance for a wide range of applications. It is compatible with Intel's 7th and 6th generation i3, i5, and i7 processors, ensuring you can harness the power of some of the latest CPUs on the market. This motherboard supports dual-channel DDR4 memory up to a maximum of 32GB, providing the speed and capacity needed for multitasking, gaming, and professional applications.
One of the standout features of the Gigabyte GA-H110M-DS2 is its integrated Intel HD Graphics. With 1GB of shared graphics memory and support for resolutions up to 1920x1200@60 Hz through the D-Sub port, this motherboard ensures you can enjoy clear, high-definition visuals without the need for a separate graphics card. This is particularly beneficial for budget-conscious users looking to build a capable system without additional costs.
Key Features of GA-H110M-DS2 Micro ATX Motherboard Price in Bangladesh
The Gigabyte GA-H110M-DS2 Micro ATX Motherboard is packed with features that enhance its performance and usability. One of the key features is the Audio Noise Guard with LED Trace Path Lighting, which ensures high-quality audio output by isolating the audio signals from potential interference. This motherboard also boasts 8-channel HD audio with high-quality audio capacitors, delivering immersive sound for gaming, multimedia, and professional use.
Connectivity is another strong suit of the Gigabyte GA-H110M-DS2. It comes with Realtek GbE LAN with cFosSpeed Internet Accelerator Software, ensuring fast and reliable network connections for online gaming, streaming, and general internet use. The dual Ultra-Fast SATA interface enhances storage performance, allowing for quicker data transfer rates and reduced load times.
Benefits of the Gigabyte H110 Motherboard Price in Bangladesh
Imagine building your dream PC with confidence, knowing that each component is top-notch and reliable. The Gigabyte GA-H110M-DS2 Micro ATX Motherboard offers peace of mind with its robust build quality and extensive compatibility. Gamers will appreciate the smooth gameplay and high-definition graphics, while professionals will benefit from the enhanced productivity and efficiency.
For students and home users, this motherboard ensures that everyday tasks such as browsing the internet, streaming videos, and working on documents are performed effortlessly. The reliability and performance of the Gigabyte GA-H110M-DS2 give users peace of mind, knowing that their PC can handle anything they throw at it.
Technical Specifications and Usage of Gigabyte GA-H110M-DS2
Specs:
- Model: Gigabyte GA-H110M-DS2
- Form Factor: Micro ATX
- CPU Support: Intel 7th/6th Gen i3, i5, i7 processors
- Memory: Dual Channel DDR4, up to 32GB
- Graphics: Integrated Intel HD Graphics, 1GB shared memory, 1920x1200@60 Hz (D-Sub)
- Audio: Audio Noise Guard with LED Trace Path Lighting, 8-channel HD audio, high-quality audio capacitors
- LAN: Realtek GbE LAN with cFosSpeed Internet Accelerator Software
- Storage Interface: Dual Ultra-Fast SATA
- BIOS: GIGABYTE UEFI DualBIOS™ Technology
- Additional Features: GIGABYTE™ APP Center, Intel® Small Business Basics
Usage Guidance:
Setting up the Gigabyte GA-H110M-DS2 Micro ATX Motherboard is straightforward. Begin by powering down your PC and unplugging it from the power source. Open your PC case and locate the motherboard mounting points. Carefully align the motherboard with the case and secure it using the appropriate screws. Connect the power supply cables, install the CPU, memory modules, and any expansion cards like a graphics card. Finally, connect all peripheral devices and power on your PC to enter the BIOS setup and configure your new hardware.
Pricing and Availability in CTG Computer
The Gigabyte GA-H110M-DS2 Micro ATX Motherboard is available for purchase in Dhaka, Bangladesh, at a price of 9800 BDT. This competitive pricing makes it an excellent option for users seeking to build or upgrade their PCs without exceeding their budget. You can find this motherboard at CTG Computer, a trusted retailer known for offering high-quality computer components.
FAQs
1. What is the price of the Gigabyte GA-H110M-DS2 Micro ATX Motherboard in Bangladesh?
The Gigabyte GA-H110M-DS2 Micro ATX Motherboard is priced at 9800 BDT in Bangladesh, making it an affordable and high-performance option for your PC build.
2. Is the Gigabyte GA-H110M-DS2 Micro ATX Motherboard compatible with Intel's 7th generation processors?
Yes, the Gigabyte GA-H110M-DS2 Micro ATX Motherboard supports Intel 7th and 6th generation i3, i5, and i7 processors.
3. What kind of memory does the Gigabyte GA-H110M-DS2 Micro ATX Motherboard support?
The motherboard supports dual-channel DDR4 memory up to a maximum of 32GB, providing high-speed data transfer and improved multitasking capabilities.
4. Does the Gigabyte GA-H110M-DS2 Micro ATX Motherboard have integrated graphics?
Yes, it has integrated Intel HD Graphics with 1GB of shared graphics memory, supporting resolutions up to 1920x1200@60 Hz through the D-Sub port.
5. How do I install the Gigabyte GA-H110M-DS2 Micro ATX Motherboard in my PC?
To install the motherboard, power down your PC, open the case, and align the motherboard with the mounting points. Secure it with screws, connect the power supply, install the CPU, memory, and any expansion cards. Connect all peripherals and power on your PC to configure the BIOS.
Upgrade your PC with the Gigabyte GA-H110M-DS2 Micro ATX Motherboard today and experience enhanced performance and reliability. Whether for gaming, professional work, or everyday computing, this motherboard is designed to meet all your needs. Add to your cart now and take the first step towards building a powerful and efficient PC!
